Power: One AA Battery (0.9V~4.2V)
Output: Maximum - 109 lumens; Moonlight - 0.2 lumens
Runtime: Maximum - 1.2 hours; Moonlight - 10 days
Strobe: Strobe, S.O.S., and Beacon flash modes
Length: 3.8 inches
Diameter: 0.86 inches
Weight: 1.8 ounces
Typical Output Levels and Runtimes + (LED drive current)
Moonlight: 0.2 lumens for 10 days (1ma)
Low: 4 lumens for 2 days (10ma)
Medium: 22 lumens for 6 hours (50ma)
High: 85 lumens for 1.5 hours (250ma)
Max: 109 lumens for 1.2 hours (350ma)
Strobe: 109 lumens for 2.5 hours
Beacon: 0-109 lumens pulse for 18 hours
Operating your Quark AA is simple. Make sure its batteries are inserted with the positive side (+) toward the head. Ensure the bezel (the 'head' of the light) and tailcap are tightened, then depress the tailcap button fully so that it 'clicks' and the light turns on.
The two most commonly used modes are Max and Moonlight, the highest and lowest modes. To access Max, you simply tighten the bezel. To access Moonlight, you just loosen the bezel a half-turn. That's it.
You can also cycle through the Quark's other modes just as easily. Lightly depress the button momentarily (you don't need to 'click' it off) and the output will switch to the next mode. The mode sequence is determined by whether the bezel is tightened or loosened:
Loosened Bezel: Moonlight -> Low -> Medium -> High -> SOS -> Beacon
Tightened Bezel: Max -> Strobe
Once the Quark has been turned off for at least three seconds, it will revert to the first level of output in the sequence, either Moonlight or Max.
4Sevens warrants its products to be free from defects in materials and workmanship. We will repair or replace, at our option, without charge, any product or part which is found to be defective under normal use and service within 120 months from the date of purchase with proof of purchase. Such repair or replacement shall be the purchaser's sole and exclusive remedy under this warranty. This warranty does not cover normal maintenance and service and does not apply to any products or parts which have been subject to modification, misuse, abuse, negligence, accident, or improper maintenance or repair by anyone other than 4Sevens.
