Length: 4.5 inches
Diameter: 0.86 inches
Weight: 1.8 ounces
Typical Output Levels and Runtimes + (LED drive current)
Moonlight: 0.2 OTF lumens for 30 days, (1ma)
Low: 4 OTF lumens for 5 days (10ma)
Medium: 22 OTF lumens for 20 hours (50ma)
High: 85 OTF lumens for 4.5 hours (250ma)
Max: 230 OTF lumens for 1.8 hours (990ma)
Strobe: 230 OTF lumens for 3 hours
Beacon:0-230 OTF lumens pulse for 23 hours
Operating your Quark 1232 is simple. Make sure its batteries are inserted with the positive side (+) toward the head. Ensure the bezel (the 'head' of the light) and tailcap are tightened, then depress the tailcap button fully so that it 'clicks' and the light turns on.
The two most commonly used modes are Max and Moonlight, the highest and lowest modes. To access Max, you simply tighten the bezel. To access Moonlight, you just loosen the bezel a half-turn. That's it.
You can also cycle through the Quark's other modes just as easily. Lightly depress the button momentarily (you don't need to 'click' it off) and the output will switch to the next mode. The mode sequence is determined by whether the bezel is tightened or loosened:
Loosened Bezel: Moonlight -> Low -> Medium -> High -> SOS -> Beacon
Tightened Bezel: Max -> Strobe
Once the Quark has been turned off for at least three seconds, it will revert to the first level of output in the sequence, either Moonlight or Max.
