The Quark Turbo features a larger, deeper reflector for improved throw! This subseries operates the same as the tactical subseries: with a significantly different UI than the regular Quarks. This UI allows the user to program both primary and secondary outputs.
Power: Two CR123A Batteries (3.0V~9.0V)
Output: Maximum - 230 lumens; Moonlight - 0.2 lumens
Runtime: Maximum - 1.8 hours; Moonlight - 30 days
Length: 4.9 inches
Diameter: 1.2 inches
Weight: 2.8 ounces
Typical Output Levels and Runtimes + (LED drive current)
Moonlight: 0.2 lumens for 30 days, (1ma)
Low: 4 lumens for 5 days (10ma)
Medium: 22 lumens for 20 hours (50ma)
High: 85 lumens for 4.5 hours (250ma)
Max: 230 lumens for 1.8 hours (990ma)
Strobe: 230 lumens for 3 hours
Beacon: 0-230 lumens pulse for 23 hours
The Quark Tactical can memorize any two modes of output, from its eight total modes, to be instantly available. These two memorized modes are accessed by either tightening or loosening the head (for example, tight can be Max, and loose can be Low).
To have your Quark Tactical memorize a different mode, turn it on and loosen the head by a half-turn. Then, tighten the head at least four times rapidly (twisting it tight, then loose, then tight, etc., four times). After the fourth time, leave the head tight or loose depending which position you want to program.
After three seconds, the light will flash, signaling it is ready to be programmed. Cycle through the eight available modes by clicking the tailcap off and on. The mode sequence is as follows:
Moonlight » Low » Medium » High » Max » SOS » Strobe » Beacon
Once you find your desired mode, leave that mode on for ten seconds and the light will flash again, confirming that the mode has been memorized. To cancel programming before it flashes, turn the light off for three seconds.
