Power: One CR123A Battery (0.9V~4.2V)
Output: Maximum - 174 ANSI lumens; Moonlight - 0.6 ANSI lumens
Runtime: Maximum - 1 hour; Moonlight - 701 hours
Strobe: Strobe, S.O.S., and Beacon flash modes
The Quark Tactical subseries operates with a significantly different UI than the regular Quarks. This UI allows the user to program both primary and secondary outputs.
Length: 3.2 inches
Diameter: 0.86 inches
Weight: 1.4 ounces
Typical Output Levels and Runtimes + (LED drive current)
Moonlight: 0.6 lumens for 701 hours, (1ma)
Low: 4 lumens for 60 hours (10ma)
Medium: 19 lumens for 13 hours (50ma)
High: 83 lumens for 162 minutes (250ma)
Max: 174 lumens for 1 hour (700ma)
Strobe: 174 lumens for 1.6 hours
Beacon: 0-174 lumens pulse for 12 hours
Operating your Quark Tactical is simple. Insert the battery with the positive side (+) towards the head. Make sure the head and tailcap are tightened, then depress the tailcap button fully so that it "clicks" and the light turns on. You can also press the tailcap lightly (you don't have to "click" it on) to activate the light momentarily. This is known as the momentary-on feature.
The Quark Tactical can memorize any two modes of output, from its eight total modes, to be instantly available. These two memorized modes are accessed by either tightening or loosening the head (for example, tight can be Max, and loose can be Low).
To have your Quark Tactical memorize a different mode, turn it on and loosen the head by a half-turn. Then, tighten the head at least four times rapidly (twisting it tight, then loose, then tight, etc., four times). After the fourth time, leave the head tight or loose depending which position you want to program.
After three seconds, the light will flash, signaling it is ready to be programmed. Cycle through the eight available modes by clicking the tailcap off and on. The mode sequence is as follows:
Moonlight » Low » Medium » High » Max » SOS » Strobe » Beacon
Once you find your desired mode, leave that mode on for ten seconds and the light will flash again, confirming that the mode has been memorized. To cancel programming before it flashes, turn the light off for three seconds.
